Converting steam and air hammers
The existing anvil block and frame are retained, and a new hydraulic power head is added together with the control systems.
Electro-Hydraulic Close Die Forging Hammer
Hydraulic Power Head for Forging Hammer
C86YT
Hydraulic power head designed to convert classic steam or compressed-air hammers into fully hydraulic equipment — small investment, short cycle, high benefit.
Overview
About this machine
The fully hydraulic power head is Anyang's solution for upgrading existing hammers: it is suitable for the conversion of steam hammers, air-compressor forging hammers and electro-hydraulic forging hammers.
The conversion delivers improved performance with a small investment and a quick implementation. A reference example is the conversion of a 10-ton C-type steam hammer completed in India.
Key data
Main specifications
- Type
- Retrofit power head
- Compatible with
- Steam & air hammers
- Benefit
- Fast return on investment
Full technical parameters are confirmed together with our engineers, based on your part and production volume.
Features
Design features and technology
Converting electro-hydraulic hammers
The existing components are reused and only the power head is replaced.
Short conversion cycle
Short conversion cycle, small investment and high benefit compared with buying a completely new machine.
Low energy consumption
Energy consumption drops significantly compared with the original steam or compressed-air drive.
High hitting frequency
High hitting frequency with striking power that remains adequate for the existing forging processes.
Precise energy management
The striking energy can be managed precisely, which improves the consistency of the forgings.
Reduced operator fatigue
Operator fatigue is considerably reduced compared with the mechanical controls of classic hammers.
In use
Applications
- Upgrading steam forging hammers
- Upgrading air-compressor driven pneumatic hammers
- Upgrading existing electro-hydraulic forging hammers
- Completed examples: Massey hammer conversion, column machining, anvil and column installation preparation
Compatible equipment
- Steam hammers of various tonnages, including C-type construction
- Air-compressor driven pneumatic forging hammers
- Electro-hydraulic forging hammers
- Previously converted makes, including Massey
Gallery
Hydraulic Power Head for Forging Hammer
Video
See it working
Technical specifications
Main technical parameters of the C86YT series hydraulic power head
Swipe the table sideways to see all models →
| Parameter | Unit | C86YT-25 (1T) | C86YT-50 (2T) | C86YT-75 (3T) | C86YT-125 (5T) | C86YT-200 (8T) | C86YT-250 (10T) | C86YT-400 (16T) | C86YT-450 (18T) |
|---|---|---|---|---|---|---|---|---|---|
| Blow energy | kJ | ≥25 | ≥50 | ≥75 | ≥125 | ≥200 | ≥250 | ≥400 | ≥450 |
| Ram weight | kg | 1000 | 2000 | 3000 | 5000 | 8000 | 10000 | 16000 | 18000 |
| Max. stroke | mm | 1000 | 1200 | 1250 | 1300 | 1350 | 1400 | 1500 | 1500 |
| Hit frequency | min⁻¹ | 55–70 | 55–70 | 55–70 | 55–65 | 50–60 | 50–60 | 50–55 | 45–50 |
| Motor power | kW | 75×1 | 75×2 | 75×3 | 75×4 | 75×5 | 75×6 | 75×8 | 75×10 |
| Min. height of close die (without dovetail) | mm | 220 | 260 | 350 | 400 | 430 | 450 | 500 | 500 |
* Values are indicative and can be adapted to your specific application requirements.
Advantages
Why choose Anyang
Energy savings
Over 90% reduction in energy consumption compared to classic steam or compressed-air hammers — a direct impact on costs and emissions.
01Easy operation
Low operating and maintenance costs, maximum production agility and minimal setup times.
02Operating safety
The system is equipped with motion-locking devices, ensuring operator protection under any working conditions.
03Robust construction
Sturdy, resilient structure designed for long-term durability and consistent performance.
